7
SPECIFICATIONS
check list
ELECTRICAL
Nominal power - rating at 230V -
9.0kW – (40A MCB rating)
PLUMBING (see page 11 & 12 for water regulations)
Supply Source - see page 11 for full details Cold water storage ONLY
Minimum capacity 114 litres (25 gallons)
Minimum head height = 8cm
Maximum head height = 10m
Minimum flow to shower inlet = 8l per minute
Maximum inlet temperature 28°C
Minimum inlet temperature 2°C
Inlet connection 15mm diameter
Outlet connection ½” BSP male thread
MATERIALS
ABS Backplate, cover, controls, showerhead
Acetal Sprayplate
Minerally insulated corrosion resistant metal
sheathing
Elements
STANDARDS and APPROVALS
Splashproof rating IP25
Safety Complies with the requirements of current
British and European safety standards for
household and similar electrical appliances
BEAB Complies with requirements of the British
Electrotechnical Approvals Board (BEAB)
CE Meets with Compliance with European
Community Directives (CE)
1
SECTION
