Triton T90SR - DIMENSIONS & ENTRY POINTS; DIMENSIONS; ENTRY POINTS

8
DIMENSIONS & ENTRY POINTS
2
check list
SECTION
Fig.2
Fig.1
ENTRY POINTS
DIMENSIONS
CABLE
Left: Bottom, Back & Top.
= Back
= Others
322mm 95mm
266mm
WATER
Left: Bottom, Back & Top.
= Back
= Others
PLEASE NOTE: Deviation from the
approved entry points will invalidate
product specifications and warranty.
