Dual control built-in thermostatic mixer shower
Fit the temperature control knob, making sure
the maximum temperature stop pin is as close
to the at edge of the maximum temperature
stop face as possible (g.17).Secure with the
tting screw once the commissioning procedure
is complete
and t the lever.
Adjusting the Maximum Temperature
Stop
To adjust the maximum temperature stop,
remove the temperature control knob and
turn the ow control on full. Once the water
temperature has stabilised, use a thermometer to
establish the temperature. Turn the spindle either
clockwise or anti-clockwise until the desired
temperature is achieved. When the desired
temperature has been achieved, turn the shower
off and ret the temperature control knob as
shown in (g.17).
Fig.17
Pin at maximum
temperature stop
Pin
Maximum
temperature
stop face
Temperature control knob
