Zanté electric shower
9
After choosing the site for the shower, use the
backplate as a template and mark the two fixing
holes (fig.12). Drill and plug to suit the fixing
screws supplied. (The wall plugs provided are
suitable for most brick walls — use an appropriate
masonry drill, but if the wall is plasterboard or a
soft building block, you must use suitable wall plugs
and an appropriate drill).
Screw the bottom fixing screw into position
leaving the base of the screw head protruding
6mm out from the wall.
Hook the backplate over the bottom screw and
fit the top fixing screw into position.
DO NOT fully tighten the screws at this stage,
as the fixing holes are elongated to allow for
out of square adjustment after the plumbing
connections have been completed.
Fig.11
Fig.10
Fig.12
