Triumph Rocket III Handbook

14
Parts Identification
1. C l u t c h l e v e r
2. Clutch lever adjuster
3. Headlight dip switch
4. Horn button
5. Indicator switch
6. Ignition switch
7. Front brake fluid reservoir
8. Front brake lever
9. Engine stop switch
10.Starter button
11. Tachometer
12.Speedometer
13 . O d o m e t e r
1 3 5 612 11 7 892
4
1013

Triumph Rocket III Specifications

General

Compression Ratio	10.0:1
Final Drive	Shaft
Transmission	5-speed
Rear Brakes	Single 316mm disc, 2-piston caliper
Front Tire	150/80 R17
Rear Tire	240/50 R16
Dry Weight	320 kg (705 lbs)
Fuel System	Electronic fuel injection
Exhaust	3-into-1 into 2
Clutch	Wet, multi-plate
Frame	Tubular steel, twin spine
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Twin 320mm floating discs, 4-piston calipers
Front Wheel	17 x 3.5 in
Fuel Tank Capacity	24 liters (6.3 US gal)
Engine Type	Liquid-cooled, DOHC, in-line 3-cylinder
