Triumph Tiger 900 GT User Manual

MAINTENANCE
159
Tiger 900 Rally, Tiger 900 Rally Pro and
Tiger 900 Bond Edition Front Suspension
Settings
Loading Condition
Compression
Damping
1
Rebound
Damping
1
Solo Riding -
Normal
8 8
Solo Riding -
Comfort (Softer)
15 15
Solo Riding -
Sport (Firmer)
3 3
Solo Riding - Off-
Road (Broken
Terrain)
18 18
Solo Riding - Off-
Road (Smooth
Terrain)
8 8
Rider and
Luggage
8 8
Rider and
Passenger
8 6
Rider, Passenger
and Luggage (not
exceeding limits)
8 6
1
Number of clicks counterclockwise from the
fully clockwise (closed) position - noting that
the first stop (click) is counted as 1.
Front Suspension Spring Preload
Adjustment
Tiger 900 Rally, Tiger 900 Rally Pro and
Tiger 900 Bond Edition
The spring preload adjuster is located at
the top of each fork.
1
1. Spring preload adjuster
To change the front spring preload
setting:
▼ Rotate the spring preload adjuster
clockwise to increase, or
counterclockwise to decrease.
▼ Always count the number of turns
forward from the fully
counterclockwise position.

Triumph Tiger 900 GT Specifications

General

Displacement	888 cc
Power	93.9 HP (70 kW) @ 8, 750 rpm
Torque	87 Nm @ 7, 250 rpm
Transmission	6-speed
Seat Height	810-830 mm (adjustable)
Tires (Front)	100/90-19
Tires (Rear)	150/70 R17
Engine Type	Liquid-cooled, 12 valve, inline 3-cylinder
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial monobloc calipers
Rear Brakes	Single 255mm disc, Brembo single piston sliding caliper
Fuel Capacity	20 L
Frame	Tubular steel frame
ABS	Switchable ABS
Traction Control	Switchable traction control
Riding Modes	Road, Rain, Sport
Rear Suspension	Monoshock, adjustable preload and rebound damping
Weight (Wet)	210 kg (463 lbs)
Instrumentation	TFT color display
