Triumph Tiger 900 GT User Manual

GENERAL INFORMATION
37
Brake Lever Adjuster
Warning
Do not attempt to adjust the levers
with the motorcycle in motion as this
may lead to loss of motorcycle control
and an accident.
After adjusting the levers, operate the
motorcycle in an area free from traffic
to gain familiarity with the new lever
setting.
Do not loan your motorcycle to
anyone as they may change the lever
setting from the one you are familiar
with causing loss of motorcycle
control and an accident.
An adjuster is mounted to the front
brake lever. The adjuster allows the
distance from the handlebar to the
brake lever to be changed to suit the
span of the rider's hands.
2
1
1. Brake lever
2. Adjuster wheel
To adjust the brake lever:
▼ Rotate the adjuster wheel to the
required position.
▼ The distance from the handlebar grip
to the released lever is shortest
when the adjuster wheel is turned
fully counterclockwise. It is the
longest when the adjuster wheel is
turned fully clockwise.

Triumph Tiger 900 GT Specifications

General

Displacement	888 cc
Power	93.9 HP (70 kW) @ 8, 750 rpm
Torque	87 Nm @ 7, 250 rpm
Transmission	6-speed
Seat Height	810-830 mm (adjustable)
Tires (Front)	100/90-19
Tires (Rear)	150/70 R17
Engine Type	Liquid-cooled, 12 valve, inline 3-cylinder
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial monobloc calipers
Rear Brakes	Single 255mm disc, Brembo single piston sliding caliper
Fuel Capacity	20 L
Frame	Tubular steel frame
ABS	Switchable ABS
Traction Control	Switchable traction control
Riding Modes	Road, Rain, Sport
Rear Suspension	Monoshock, adjustable preload and rebound damping
Weight (Wet)	210 kg (463 lbs)
Instrumentation	TFT color display
