Triumph Tiger 900 GT User Manual

MAINTENANCE
167
Rear Suspension Rebound Damping
Adjustment
Tiger 900 GT and Tiger 900 GT (LRH)
The rebound damping adjuster is
located at the bottom of the rear
suspension unit and is accessible from
the left hand side of the motorcycle.
1
1. Rebound damping adjuster
To change the rebound damping setting:
▼ Rotate the slotted adjuster clockwise
to increase (harder suspension) and
counterclockwise to decrease (softer
suspension).
▼ The setting is measured as the
number of adjuster turns
counterclockwise from the fully
clockwise position.
Rear Suspension Rebound Damping
Adjustment
Tiger 900 Rally, Tiger 900 Rally Pro and
Tiger 900 Bond Edition
The rebound damping adjuster is
located at the bottom of the rear
suspension unit and is accessible from
the left hand side of the motorcycle.
1
1. Rebound damping adjuster
To change the rebound damping setting:
▼ Rotate the slotted adjuster clockwise
to increase (harder suspension) and
counterclockwise to decrease (softer
suspension).
▼ The setting is measured as the
number of adjuster turns
counterclockwise from the fully
clockwise position.

Triumph Tiger 900 GT Specifications

General

Displacement	888 cc
Power	93.9 HP (70 kW) @ 8, 750 rpm
Torque	87 Nm @ 7, 250 rpm
Transmission	6-speed
Seat Height	810-830 mm (adjustable)
Tires (Front)	100/90-19
Tires (Rear)	150/70 R17
Engine Type	Liquid-cooled, 12 valve, inline 3-cylinder
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial monobloc calipers
Rear Brakes	Single 255mm disc, Brembo single piston sliding caliper
Fuel Capacity	20 L
Frame	Tubular steel frame
ABS	Switchable ABS
Traction Control	Switchable traction control
Riding Modes	Road, Rain, Sport
Rear Suspension	Monoshock, adjustable preload and rebound damping
Weight (Wet)	210 kg (463 lbs)
Instrumentation	TFT color display
