Triumph Tiger 900 GT User Manual

MAINTENANCE
166
Rear Suspension Spring Preload
Adjustment
Tiger 850 Sport, Tiger 900 GT and
Tiger 900 GT (LRH)
The spring preload adjuster is situated
on the right hand side of the
motorcycle, at the top of the rear
suspension unit.
1
1. Spring preload adjuster
To change the spring preload setting:
▼ Rotate the spring preload adjuster
clockwise to increase, or
counterclockwise to decrease.
▼ The setting is measured as the
number of adjuster turns clockwise
from the fully counterclockwise
position.
Rear Suspension Spring Preload
Adjustment
Tiger 900 Rally, Tiger 900 Rally Pro and
Tiger 900 Bond Edition
The spring preload adjuster is situated
on the right hand side of the
motorcycle, at the top of the rear
suspension unit.
1
1. Spring preload adjuster
To change the spring preload setting:
▼ Rotate the spring preload adjuster
clockwise to increase, or
counterclockwise to decrease.
▼ The setting is measured as the
number of adjuster turns clockwise
from the fully counterclockwise
position.

Triumph Tiger 900 GT Specifications

General

Displacement	888 cc
Power	93.9 HP (70 kW) @ 8, 750 rpm
Torque	87 Nm @ 7, 250 rpm
Transmission	6-speed
Seat Height	810-830 mm (adjustable)
Tires (Front)	100/90-19
Tires (Rear)	150/70 R17
Engine Type	Liquid-cooled, 12 valve, inline 3-cylinder
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial monobloc calipers
Rear Brakes	Single 255mm disc, Brembo single piston sliding caliper
Fuel Capacity	20 L
Frame	Tubular steel frame
ABS	Switchable ABS
Traction Control	Switchable traction control
Riding Modes	Road, Rain, Sport
Rear Suspension	Monoshock, adjustable preload and rebound damping
Weight (Wet)	210 kg (463 lbs)
Instrumentation	TFT color display
