P. 42 — User manual V3
Charging the battery of your
electric power assist system
When should the battery be charged?
Charge the battery as needed. For instance,
if you only use your Azteca for brief periods
and for short rides, the battery can be
recharged after a few such rides.
If, on the other hand, you are planning a long
ride of 40 km/25 miles or more, it is best
to fully charge your battery before leaving.
Generally speaking, if the battery charge
indicator on the display indicates there is
less than a 50 % charge remaining, charging
the battery is recommended.
You may charge your battery at any time,
as this type of battery does not have any
‘memory effect’ and the charger is of the
‘smart type’; it will stop charging by itself
once the battery is fully charged.
The battery must be charged at least every
two months.
A full charge of a battery when empty
should take a maximum of 8 hours. to
complete.
If your battery is not fully charged after 8
hours, unplug it immediately and contact
a Trivel authorized dealer for a charger
battery malfunction diagnostic.
Never leave the battery connected to the
charger for more than 24 hours!
To charge the battery:
1.
Connect the AC power plug into the
charger.
2.
Plug the AC power plug into an
electrical outlet. The LED indicators on
the charger will light up to confirm that
current is flowing: Power red – Charge
green.
3.
Lift the rubber protector cap on the
battery and connect the charging plug
into the socket.
4.
The LED charge indicator on the charger
will turn red confirming that charging
is underway.
5.
Let the battery charge until it is fully
charged. When fully charged the light
on the charger will turn green.
6.
Pull the charging plug from the battery
and replace the rubber protector cap.
