Trojan ELLIPTI-CYCLE 200 User Manual

1569-5
3. HARDWARE LIST
NOTE :
The described parts are all you need to assemble this machine.
Before starting assembly, please check the hardware packing to make sure they are included.
No. Description Q’ty
12
Carriage Bolt (M8 x 60mm)
4
11
Screw (M8 x 15mm)
8
14
Cap Nut (M8)
8
36
Washer (ø10 x 26mm)
4
15
Arc Washer (ø8 x 19mm)
16
68
Nut Cap (19#)
4
No. Description Q’ty
42
Carriage Bolt (M8 x 70mm)
4
53
Hex Head Screw (3/8” x 45mm)
4
39
Nylock Nut (3/8”)
4
M5 Allen Wrench
1
M8 Allen Wrench
1
Screw Driver
1
