13
SEAT ADJUSTMENT (UP AND DOWN)
To adjust the seat height, slacken the spring Knob on the Vertical Post Stem on the main frame and pull
back the Knob. Position the Vertical Seat Post for the desired height so that holes are aligned, then release
the Knob and retighten it.
SEAT ADJUSTMENT (BACKWARDS AND FORWARDS)
To move the seat forward in the direction of the handlebar or backwards away from it, loosen the
adjusting Knob and washer and pull the Knob back. Slide horizontal seat post into desired position.
Align holes and then retighten the adjusting Knob.
HANDLEBAR HEIGHT ADJUSTMENT
To adjust the handlebar height, slacken the spring Knob and secondary Knob and pull both Knobs back.
Slide the handlebar post along the housing on the main frame to the desired height and, with the holes
aligned correctly, tighten the spring adjusting Knob and then the secondary Knob.
SEAT ADJUSTMENT
