16
STEP 9: INSTALLING THE
MIDDLE HANDLEBAR
Attach the Middle Handlebar (5) to the Front Post (4)
and tighten them with 2 Spring Washers (P)
and 2 Bolts (Q).
ASSEMBLY STEPS
STEP 9
STEP 10: INSTALLING THE CONSOLE
Unfasten the Screws (R) in the Console (6), and
connect the Console Wire (28c, b).
Attach the Console (6) to the Console Bracket on
the Front Post (4). Tighten the 2 Screws (R) with
2 Washers (Y).
STEP 10
