HARDWARE & TOOLS LIST
INSTRUCTIONS FOR ASSEMBLY
• Before you start to assemble, please check the hardware packaging to make sure all parts are included.
• Basic tools, such as spanners will be provided for assembly.
#22M05T003 TR510 Treadmill - User Manual.indd 6 2022/05/25 14:49
1. Base (1 PC) 3. Left Upright (1 PC) 4.Right Upright (1pc) 86. Console (1 PC)
44. Left Base Cover (1 PC)
45. Right Base Cover (1 PC)
8. Bolt (M10 x 50 mm)
(2 PCS)
9. Bolt (M10 x 20 mm)
(2 PCS)
13. Bolt (M8 x 15 mm)
( PCS)4
22. Screw (M5 x 12 mm)
(4 PCS)
33. Washer (M10)
(4 PCS)
34. Washer (M8)
( PCS)4
Screwdriver (1 PC)39. Safety Key (1 PC)
Lubricant Oil (1 PC)
Wrench #5 (1 PC) Wrench #6 (1 PC)
To Next Page
