Trojan TR510 - Parts List

7
PARTS LIST
No. Description Qty
1 Base 1
2 Main Frame 1
3 Left Upright 1
4 Right Upright 1
5 Console Rack 1
6 1
7 Bolt (M10 x 45) 4
8 Bolt (M10 x 50)
9 Bolt (M10 x 20) 2
10 Bolt (M8 x 45) 1
11 Bolt (M8 x 40) 4
12 Bolt (M8 x 25) 1
13 Bolt (M8 x 15) 4
14 Bolt (M8 x 65) 2
15 Bolt (M8 x 55) 1
16 Bolt (M8 x 15) 4
17 Bolt (M8 x 10) 2
18 Bolt (M6 x 25) 8
19 Bolt (M6 x 20) 2
20 Bolt (M5 x 28) 8
21 Bolt (M5 x 10)
22 Bolt (M5 x 12) 4
23 Bolt (M4 x 8) 2
24 Bolt (M3 x 6) 8
25 Bolt (M4 x 12) 19
26 Bolt (M4 x 15) 4
27 Bolt (M4 x 15) 2
28 Bolt (M4 x 10) 14
29 Bolt (M5 x 15) 2
30 Nut (M10) 6
No. Description Qty
31 Nut (M8) 6
32 Nut (M5) 8
33 Washer (M10) 14
34 Washer (M8) 8
35 Spring Washer (M8) 6
36 Console Plastic Housing 1
37 Console rear Cover 1
38 Console Chip 1
39 Safety Key 1
40 Motor Cover 1
41 Rear End Cap Left 1
42 Rear End Cap Right 1
43 Power Rack 1
44 Left Base Cover 1
45 Right Base Cover 1
46 Bolt (M8 x 70) 1
47 Foot Rail 2
48 Belly Pan 1
49 Motor Belt 1
50 Cushion 6
51 Spring Cushion 4
52 Air Cushion 2
53 Base Foot Pad 4
54 Base Cushion 2
55 Handrail Buttom Left 1
56 Handrail Buttom Right 1
57 Base Wheel 2
58 Frame Wheel 2
59 Incline Frame 1
#22M05T003 TR510 Treadmill - User Manual.indd 7 2022/05/25 14:49
4
10
Bolt
(M10 x 55)
