PARTS LIST
No. Description Qty
60 Base Cap (38 x 38) 2
61 Handrail End Cap 2
62 Handrail Foam 2
63 Running Deck 1
64 Running Belt 1
65 Foot Rail Fastener 8
66 Cable Grommet 1
67 Motor 1
68 Controller 1
69 Power Switch 1
70 Circuit Breaker 1
71 Power Rack 1
72 Magnetic Ring 1
73 Front Roller 1
74 Rear Roller 1
75 Air Cylinder 1
76 Wire Clip 1
No. Description Qty
89
Base Cap (20 x 40) 4
90 Bolt (M10 x 40) 1
#22M05T003 TR510 Treadmill - User Manual.indd 8 2022/05/25 14:49
Red AC Wire (L= 400 mm)
Black AC Wire (L= 400 mm)
Red AC Wire (L= 100 mm)
1
Power Cord
1
78
81
80
79 1
1
Contol Cable (L= 1400 mm)
Incline Motor
86
83
87
Console set
1
85
1
82
1
1
Motor Base 1
84 Photonic Sensor Rack
Photonic Sensor
1
88 Speaker 2
91
Left speaker cover 1
92 Right speaker cover 1
93 Console overlay 1
