Viewing Project Data
The Model 2701-B offers two methods of viewing data. You
can view either the last measurement results using the Recall
function described on page 4–12, or any measurement results,
including project notes, stored in a project file using the View
function available from the Project menu.
1. To view data stored in a project file, press 〈2〉 at the
Project menu. The gauge displays:
2. Use the arrow keys to scroll through the project names.
3. Press 〈ENTER/START〉, when the gauge displays the
desired project name.
If any measurement data has been stored in the selected
project file, the gauge displays the data for the first
measurement.
Five screens of information are displayed for each
measurement. Use the up and down arrows to scroll
through the project data.
4. Press the 〈ESC〉 key to return to the project selection
screen shown above.
Pr j : XXX
mm/ dd/ yy hh: mmp
Rec : # UI D: XXX
<ENTER> t o sel ect
