CHAPTER 2: ASSEMBLY INSTRUCTIONS
TREADMILL ASSEMBLY STEPS (continued):
STEP 5: Console Rack Cable Connections:
a) Connect the COAX, AUXPS,
COMM and CNTRL cables coming
from the right pedestal to the
corresponding wires in the console
rack.
NOTE: All four connections are made
for any Console model.
STEP 6: Handrail Installation:
a) Insert Handrails (E, F) onto
Pedestals and secure with 4 Bolts -M8
x 80mm (e) and Internal Tooth
Washer M8 (d) using 5 mm Hex Key.
Required Hardware:
4 M8 x 80mm bolts (e)
4 Internal Tooth M8 Washers (d)
STEP 7: Top Shoulder Covers:
a. Using a Phillips screwdriver, install
Shoulder Cover Top pieces Left (G)
and Right (H) with three Screws M4 x
10mm (c) on each side as shown.
CAUTION: Make sure cabling is
NOT pinched during installation.
Required Hardware:
6 M
4 x 0.7 x 10mm screws(c)
