TR-36RBF INSTALL GUIDE
07/28/2021 Page 25 of 48TEC_TM_151 | REV. A | EN
CABINET SETUP
FREEZER STORAGE
The freezer drawer of the cabinet is divided into
two sections. The top section holds the ice bin
(see fig. 1).
NOTE: IT IS NOT RECOMMENDED TO REMOVE THE
ICE BIN, EVEN IF THE ICEMAKER IS NOT IN USE.
THE ICE BIN PREVENTS PRODUCT DAMAGING THE
ICEMAKER.
DRAWERS
See the instructions below for drawer removal or
reinstallation.
DRAWER REMOVAL
1. Fully open the drawer.
2. With a Phillips screwdriver, remove the drawer
slide screws. See fig. 2.
3. Lift the drawer from the unit.
DRAWER INSTALLATION
1. Pull the drawer slides fully forward.
2. Slide the drawer into position until the drawer
rests under the rear hooks on the drawer slides.
3. With a Phillips screwdriver, fasten the drawer to
the drawer slides.
FIG. 1.
Do not remove the ice bucket.
FIG. 2.
Drawer slide screw locations. Not all locations shown.
