TRUE RESIDENTIAL
®
TEC_TM_151 | REV. A | EN07/28/2021Page 12 of 48
SITE PREPARATION
ANTI-SWEAT FOAM END PANELS
When installing two or more True units side-by-side, be sure to leave at least a 5/8” (15.88 mm) gap
between the cabinets, or install foam pads between the cabinets and on any side with 0” clearance,
to prevent moisture from developing on applications.
If installing anti-sweat foam end panels, True recommends applying a panel to each of the units
being joined together. To order foam pads, contact our parts department at 844-849-6226 or
TrueResidentialParts@TrueMfg.com.
NOTE: DIMENSIONS MAY VARY BY ± 1/8” (3.175 mm)
