1-10 800TCU User’s Guide 800gench1.fm Rev. A
General Information Standard Option Specifications
True Simultaneous Generator Mode
The Generator continues output Generator Code even while the unit is in the Translator
mode.
Extended Baud Rate Range
Data Rate: Selectable, 300, 600, 1200, 2400, 4800 and 9600 bps
See Table 1-3
Transformer-coupled Input
Impedance: 600 Ω balanced
Connector: Female isolated BNC, J1
Balanced Code Output
Amplitude: Adjustable, 0 to 6 Vpp into 600 Ω
Connector: 5-pin Barrier Strip
Pin Assignment: Pin 1: High
Pin 2: Low
Pin 3: Ground
1.9.1 IEEE-488 Interface
Most standard protocols are supported. The device address is programmable at the front
panel. See Chapter 2 for the I/0 command structure.
