800gench1.fm Rev. A 800TCU User’s Guide 1-11
Standard Option Specifications General Information
1.9.2 Pin Assignments
Table 1-1 Parallel BCD Pin Assignments
Pin Number Assignment Pin Number Assignment
(1) [1] NOT USED (28) [10] TMC1
(2) [34] NOT USED (29) [43] TMC2
(3) [18] NOT USED (30) [27] TMC4
(4) [2] NOT USED (31) [11] UHC1
(5) [35] mSC1 (32) [44] UHC2
(6) [19] mSC2 (33) [28] UHC4
(7) [3] mSC4 (34) [12] UHC8
(8) [36] mSC8 (35) [45] THC1
(9) [20] hSC1 (36) [29] THC2
(10) [4] hSC2 (37) [13] UDC1
(11) [37] hSC4 (38) [46] UDC2
(12) [21] hSC8 (39) [30] UDC4
(13) [5] tSC1 (40) [14] UDC8
(14) [38] tSC2 (41) [47] TDC1
(15) [22] tSC4 (42) [31] TDC2
(16) [6] tSC8 (43) [15] TDC4
(17) [39] USC1 (44) [48] TDC8
(18) [23] USC2 (45) [32] HDC1
(19) [7] USC4 (46) [16] HDC2
(20) [40] USC8 (47) [49] NOT USED
(21) [24] TSC1 (48) [33] DATA VALID
(22) [8] TSC2 (49) [17] DATA READY
(23) [41] TSC4 (50) [50] GROUND
(24) [25] UMC1
(25) [9] UMC2
(26) [42] UMC4
(27) [26] UMC8
( ) REAR PANEL FEMALE CONNECTOR PIN NUMBER
[ ] MATING MALE CONNECTOR PIN NUMBER
