1-6 800TCU User’s Guide 800gench1.fm Rev. A
General Information Signal Specifications
1.8.3 Synchronized Generator Specifications
General Specifications, Sync Generator
Days Reset: Resets to day 1 after day 365
Leap Year: Resets to day 1 after day 366 on the day armed
Phase Correction: Automatic, 500 ns corrections
Front-panel Controls and Indicators:
Operating Mode
Translator Time and Generator Time
Status Messages
Leap Year and Time Base Select
Error Bypass Select
Prop. Delay, Input Code Polarity and Filter
Sync Gen Input Code and Gen Code
Oscillator Discipline Complete Status
Video Mixer Controls
Auto Advance/Retard Direction and Rate
Code Input, Carrier
Format: Amplitude modulated IRIG-B
Tracking Range: 1 kHz ±1x10E
-5
Amplitude: 0.1 to 10 Vpp
Impedance: 100 kΩ to ground
Polarity: Selectable, positive or negative
Direction: Forward
Ratio: Adjustable, 2:1 to 5:1
Code Input, DC-shift (Optional, see Top Assembly)
Format: DC-shift IRIG-B
Tracking Range: 100 PPS ±1x10E
-5
Amplitude: 0 VDC, ±0.5 VDC to +5 VDC
Impedance: 74HC input
Timing: Rising edge on time
Direction: Forward
