2-12 800TCU User’s Guide 800gench2.fm Rev. A
Installation and Operation
Example Write: EB00<CR>
Select no Error Bypass
FORWARD (FW)
This command is used to place the Translator in the forward direction.
Example Read: FW<CR>
Translator is placed in the forward direction
TIME FREEZE (FZ)
This command will cause the 800 TCU to freeze its current time. The next TIME “TI”
command will cause the time previously frozen to be returned.
Example Read: FZ<CR>
The current time in the 800 TCU is frozen
GENERATOR CODE SELECTION (GC)
This command is provided to return or load the Generator code. The response code
returned or transmitted for a particular code will be one of the following:
Example Read: GC<CR>
Example Response: 2<LT>
Unit has IRIG-B selected.
Example Write: GC0<CR>
Select IRIG-G Generate code.
Response Code Time Code
0IRIG-G
1IRIG-A
2IRIG-B
3IRIG-E
4XR3
5 2137
