800gench2.fm Rev. A 800TCU User’s Guide 2-3
Installation and Operation
To change a parameter use the SETUP and ENTER keys in conjunction with the number
keys.
If the cursor is flashing and you wish to abort the change mode, press SETUP. The cursor
will stop flashing and pressing a number key will change the prompt not the parameter.
For Models 820 or 840 use the following example to select Positive Polarity mode and
three frames of Error Bypass:
• Press key #4 until the current Error Bypass selection is displayed.
• Press SETUP and the cursor will flash. Sequentially pressing and releasing any
number key will scroll the possible Error Bypass settings through the display. When
3 frames is displayed press ENTER.
• Press key #5 until FILTER CONTROL is displayed. Press SETUP and the display
will read CHANGE FILT CTRL and the current setting will be displayed. Off/On is
the filter status and Inverted/Non-inverted is the polarity setting. Press any number
key and the display will scroll through the four possible settings. When
Off/Non-inverted is displayed, press ENTER.
For Model 814, press START and use the following procedure to select the
Advance/Retard Rate:
• Press key #4 until the current Advance/Retard selection is displayed.
• Press SETUP and the current setting will be displayed and the cursor will be
flashing. Sequentially pressing and releasing any number key will scroll the
possible Advance/Retard selections through the display. When the desired rate is
displayed press ENTER.
Experiment with the keys to get the feel of the options that are supplied and the methods
of changing the various parameters associated with them. Again, if SETUP is pressed and
the flashing cursor does not appear, the displayed parameter is fixed and may not be
changed.
2.4 Detailed Key Information
This section provides details when using the available keys.
Key 0:
Selects the OPERATIONAL MODE display. From this display the Generator,
Synchronized Generator and Translator modes may be selected.
Key 1:
Toggles the alphanumeric display between the GENERATOR TIME and the
TRANSLATOR TIME displays. Pressing SETUP will cause the cursor to flash indicating
that the time may be changed. Use the number keys and the left/right arrow keys to select
the desired time (in the Translator and Sync Gen. modes the preset time will be accepted.
However, it will be corrected to the time contained on the input code).
