800gench1.fm Rev. A 800TCU User’s Guide 1-3
Power Specifications General Information
1.6 Power Specifications
The input power specifications are:
Voltage: 95 to 260 VAC
Frequency: 47 Hz to 440 Hz
Power: Approximately 15 Watts
1.7 Option Identification
Each of the options that are supplied with this unit are indicated in the Table of Contents
by an (X). Custom Options/Configurations are described on page iii of the manual index.
1.8 Signal Specifications
1.8.1 Generator Specifications
General Specifications, Generator
Days Reset: Resets to day 1 after day 365
Leap Year: Resets to day 1 after day 366
Advance/Retard Rates: 0.5 µs, 1 µs, 10 µs, 100 µs, 1 ms, 10 ms, 100 ms, 500 ms
and 1 second
Front-panel Controls and Indicators:
Operating Mode
Generate Time
Status Messages
Leap Year and Time Base Select
Advance/Retard Rate
External Start
Generate Code
Video Mixer Controls
Front-panel Controls Disable
Start and Stop
Internal Oscillator (STD)
Frequency: 10 MHz
Stability: < 50 PPM, 0 to +50° C
Aging: < 1 PPM/year
