1-12 800TCU User’s Guide 800gench1.fm Rev. A
General Information Standard Option Specifications
Table 1-2 IRIG PB1 Connector Pin Assignment
Pin Signal Pin Signal
A DOY 2 EE 8 d TOD 2 EE 10
B DOY 2 EE 7 e TOD 2 EE 9
C DOY 2 EE 6 f TOD 2 EE 8
D DOY 2 EE 5 h TOD 2 EE 7
E DOY 2 EE 4 j TOD 2 EE 6
F DOY 2 EE 3 k TOD 2 EE 5
H DOY 2 EE 2 m TOD 2 EE 4
J DOY 2 EE 1 n TOD 2 EE 3
K DOY 2 EE 0 p TOD 2 EE 2
L TOD 2 EE 26 r TOD 2 EE 1
M TOD 2 EE 25 s TOD 2 EE 0
N TOD 2 EE 24 t P1
P TOD 2 EE 23 u P2
R TOD 2 EE 22 v SPARE
S TOD 2 EE 21 w GND
T TOD 2 EE 20 x GND
U TOD 2 EE 19 y GND
V TOD 2 EE 18 z GND
W TOD 2 EE 17 AA INHIBIT
X TOD 2 EE 16 BB SPARE
Y TOD 2 EE 15 CC SPARE
Z TOD 2 EE 14 DD SPARE
a TOD 2 EE 13 EE GND
b TOD 2 EE 12 FF SPARE
c TOD 2 EE 11 HH CHASSIS
