2-6 800TCU User’s Guide 800gench2.fm Rev. A
Installation and Operation
simultaneously and any number keys to select the desired delay.The unit will
synchronize to the input code and the time will be early with respect to the input code
by the amount set into the Propagation Delay.
Key 6:
Selects the GENERATE CODE, TRANSLATE CODE and SYNC GEN REF CODE
displays. Pressing SETUP will cause the cursor to flash indicating that the Code Selection
may be changed. Repeatedly pressing a number key will scroll the possible formats
through the display. Press the ENTER key to save the code selected.
Key 7:
Programmes the various parameters associated with the Video Time Inserter (Mixer)
option.
To program for this option repeatedly press this key to scroll through the possible change
displays, then use the SETUP key to select the desired feature. Use of the ENTER key is
not required. The following list shows each of the possible displays in the order of
appearance with a brief description of each feature.
1. VIDEO PORT SELECT: When the second video port option is installed, this display
provides port selection (1 or 2). The variables described below pertain only to the port
selected.
2. VIDEO MIXER ON-OFF: ON selects the time insertion mode; OFF passes the video
signal through without time information.
3. BACKGROUND OFF-WHITE-BLACK: The time is surrounded by a white, black or
no mask as determined by this parameter.
4. INTENSITY: From this display, the arrow keys are used to increase or decrease the
intensity of the digits.
5. DAYS DIGITS ON-OFF: This display allows the user to either enable or defeat the
three days digits in the inserted time.
6. FRAC SEC: This display enables user to change the resolution or completely cancel
out the insertion of the fractional-seconds time information. The possibilities are:
None, milliseconds resolution, hundredths-of-seconds resolution and
tenths-of-seconds resolution.
7. HORIZ POSITION: Pressing the left and right arrow keys will move the horizontal
position of the inserted time.
8. VERT POSITION: Pressing the left and right arrow keys will move the vertical
position of the inserted time.
9. HORIZ CHAR SIZE: Pressing the left and right arrows will increase and decrease the
horizontal size of the inserted characters. Use this display in conjunction with the
VERT CHAR SIZE to achieve the desired aspect ratio.
10. VERT CHAR SIZE: Pressing the left and right arrows will increase and decrease the
vertical size of the inserted characters.
FWD is used to start the Translator in the forward direction. The FWD indicator will be
illuminated when the unit is in the forward mode. Pressing STOP will halt the Translator.
