3EN
– Do not put the ready-to-operate remote control in your
pocket or lay it down, otherwise functions could be trig-
gered accidentally via the control knob or slide control.
– Never tow the caravan with the drive rollers engaged, as
this may cause damage to the tyres, the towing vehicle and
the drive units.
– All wheels and tyres on the caravan must be of the same
size and type. If this is not observed, safe operation is not
guaranteed.
– To ensure that the MoverXT / XT2 works properly, the gap
between the tyres and the disengaged drive rollers must
be 20 mm. All tyres must be inflated to the same pressure
in accordance with manufacturer's instructions and be
checked regularly. Tyre wear or the fitting of new tyres may
make it necessary to readjust the gap between the drive
rollers and the tyres (see “Fitting the drive units”).
– When jacking up the vehicle, do not use the Mover XT / XT2
as a support point as this could damage the drive unit and
the vehicle.
– Sensitive objects such as cameras, DVD players etc. must
not be kept in the stowage box near the control unit or the
motor cables, as the powerful electromagnetic fields may
damage them.
– The empty weight of the vehicle increases by the weight
of the Mover XT / XT2, which reduces the payload of the
vehicle.
– Remove the plug/ adapter from the safety socket after
manoeuvring, otherwise the battery will be discharged.
Quiescent current with plug/ adapter inserted < 80 mA.
Quiescent current with plug/ adapter unplugged < 150 µA.
General instructions
The Mover XT has been designed to cope with inclines of up
to approx. 25 % bearing a gross weight of 1200 kg or 13 %
bearing a gross weight of 2300kg on a suitable surface.
The Mover XT2 has been designed to cope with inclines of up
to approx. 25 % bearing a gross weight of 1200 kg or 10 %
bearing a gross weight of 2400kg on a suitable surface.
Depending on the weight of the caravan, the MoverXT / XT2
cannot overcome obstacles from a height of about 3cm with-
out an aid (use ramps).
Due to the characteristic properties of a radio signal, it may be
interrupted by terrain / objects. This reduces reception quality
in small areas around the caravan, as a result of which the op-
eration of the Mover XT / XT2 may be briefly interrupted.
When the Mover XT / XT2 is switched off using the re-
mote control, the control unit remains in standby. To
completely switch it off, the battery must be disconnected or
isolated from the power supply via a previously installed cir-
cuit breaker.
Power supply
For optimum operation, we recommend the Truma
PowerSetBC and high-performance Optima® batteries.
Drive, lighting and gel batteries with sufficient capacity
arealso suitable.
Batteries
Recommended battery capacities
Button cell technology at least 38 Ah
Gel / AGM at least 48 Ah
Lead-acid battery (liquid gel electrolyte) at least 75 Ah
Starter batteries are not suitable
Batteries with greater capacity allow the equipment to
be used for longer.
Charger
For optimum battery charging we recommend the Truma
BC 10 charger, which is suitable for all battery types up to
200 Ah.
Notes for handling batteries
– When handling batteries, pay attention to the manufac-
turer's safety instructions and data sheets
– Ensure that the terminal clamps are secure.
– Secure battery poles with protection caps in order to pre-
vent a short circuit
– When removing the battery, first disconnect the earth con-
nection (negative terminal), followed by the positive termi-
nal. When installing the battery, first connect the positive
terminal followed by the negative terminal.
Battery care (including maintenance-free
batteries)
In order to achieve a long battery service life, attention must
be paid to the following points:
– Batteries should be fully charged before and after current is
drained;
– for stationary periods of longer than 24 hours, interrupt
power circuit (e.g. using circuit breaker or by disconnecting
the battery poles),
– for longer stationary periods, the battery must be discon-
nected and charged for 24 hours at least every 12 weeks.
In winter, store the fully charged battery in a cool, frost-
free place and recharge it regularly (every 12weeks).
Function description
Always observe the operating instructions and the
“Safety instructions” prior to starting. The vehicle owner
is responsible for correct operation of the device.
Remember that the MoverXT is suitable only for single-
axle caravans and the MoverXT2 only for two-axle
caravans.
The MoverXT / XT2 is a manoeuvring system with which a
caravan can be moved without the help of the towing vehicle.
It consists of two separate drive units, each with its own 12V
DC motor. These units are mounted on the frame of the vehi-
cle in the immediate vicinity of the wheels, and are connected
by a lateral bar.
