4 EN
Once the drive rollers have been engaged against the tyres,
using the remote control, the MoverXT / XT2 is ready for
operation. It is operated exclusively via the remote control,
which transmits radio signals to the control unit. A separately
installed 12V lead-acid battery or suitable lead-gel battery
(not supplied) provides the control unit with electrical power.
Always completely engage the drive rollers. If the drive
rollers are not completely engaged, the caravan cannot
be controlled. If this is not observed, there is a risk of injury
and property damage.
Intended use
The Mover XT was designed for use on single-axle
caravans with a gross weight of up to 2300 kg.
The Mover XT2 was designed for use on dual-axle
caravans with a gross weight of up to 2400 kg.
The MoverXT / XT2 weighs approx. 28 kg.
Check the maximum towable weight for your towing
vehicle and the gross weight of your caravan to make
sure that they are designed for this additional weight.
Approval
The Truma MoverXT / XT2 has design approval, and a “gen-
eral operating permit” (ABE) has been issued for Germany.
Acceptance by a vehicle expert is not required (except when
installing the low chassis kit). The general operating permit
(ABE) must be kept in the vehicle.
The MoverXT / XT2 complies with other requirements of
EC Directives and Standards (see Declaration of conformity).
When installing the MoverXT / XT2, the technical and admin-
istrative regulations of the country of first registration of the
vehicle must be observed.
Any modifications made to the device, or the use of any spare
parts or functionally significant accessories other than original
Truma parts, or failure to comply with the contents of the op-
erating and installation instructions invalidates the warranty
and precludes any liability claims. This will also invalidate the
operating permit for the equipment.
Operating instructions
Remote control
Protect the remote control from moisture and direct
sunlight.
1234
a
b
c
h
i
h
i
LED
Figure 1
Switching on the remote control
No other remote control function must be active when
the remote control is switched on.
a = On / off slide switch (also the emergency stop switch)
On (LED 4 lights up*)
Off (LED 4 goes off)
* LED 4 flashes for approx. 5 seconds after the remote con-
trol is switched on, until the system is ready for operation.
The following options are available for controlling the caravan:
b using the control knob only
c using the slide control only
b + c using the control knob and the slide control
The caravan symbol on the control knob indicates the current
direction of travel (of the caravan).
The slide control allows the caravan to be moved forwards
and backwards without jolting, with infinitely variable speed
control.
Slide control only
(Forwards, backwards and infinitely variable speed control)
– Slide control forward –> caravan moves forward (towards
the drawbar)
(both wheels rotate in forward direction)
– Slide control backward –> caravan moves backward (away
from the drawbar)
(both wheels rotate in reverse direction)
The further the slide control is moved from the zero position,
the faster the speed.
Only MoverXT control knob
Turns on the spot without forward or backward movement
– Turn to the right -> caravan drawbar moves to the right, left
wheel rotates forwards – right wheel rotates backwards,
rotation around middle of caravan
– Turn to the left -> caravan drawbar moves to the left, left
wheel rotates backwards – right wheel rotates forwards,
rotation around middle of caravan The further the control
knob is moved, the faster the caravan turns on the spot.
