S1/S2 Assembly Instructions – Rev N Page 17
10.1 LOCKABLE LID FOR SUPPLY CADDY
• Loosen Z-Nut from screw but do not remove.
• Rotate Z-Nut so it slides into the channel.
• Lower entire lid until it rests on the Caddy.
• Fasten lid to pole by using Torx Security L-Key (provided)
and turn screw until tight.
