4
2. ELECTRONICS
2.1 Summary of Board Connectors
Main board top
Connector
Description
DCIN1
DC Jack
Pin
Description
1
12V
2
GND
3
GND
4
12V
CON1
CON5
CON6
CON12
CON11
CON9
CON3
CON2
DCIN1
