DA210/ DA310/ DA220/ DA320
Bar Code Printer Service Manual
21
4. Remove four screws to replace
the media holder base
assembly.
5. Push the media holder base
assembly to the end for
installing the spiral sprint
assembly back.
6. Install the lower cover that
including spiral sprint.
