TSC DA210 Series User Manual

9
DA220HC/DA320HC Series (Models for Healthcare Applications)
Model
DA220HC
DA320HC
Resolution
8 dots/mm (203 dpi)
12 dots/mm (300 dpi)
Printing Method
Direct Thermal
Max. Print Speed
152.4 mm (6")/second
102 mm (4")/second
Max. Print Width
108 mm (4.25")
105.7 mm (4.16")
Enclosure
 Double-walled plastic
 Disinfectant-ready plastic
 Antibacterial enclosure
Physical Dimension
172 mm (W) x 165 mm (H) x 195 mm (D)
6.77" (W) x 6.50" (H) x 7.68" (D)
Weight
1.5 kg (3.31 lbs.)
Label Roll Capacity
127 mm (5") O.D.
Processor
32-bit RISC CPU
Memory
 128 MB Flash memory
 64 MB DRAM
Interface
 PCBA1: USB 2.0 high speed mode, USB Host, RS-232 and Ethernet (standard)
 PCBA2: USB 2.0 and Ethernet (factory option)
Power
External universal switching power supply
 IEC 60601-1 certified power supply
 Input: AC 100-240V, 2.0A, 50-60Hz
 Output: DC 24V, 2.5A, 60W
User Interface
1 power switch, 1 feed button, 1 LED (3 colors: green, amber & red)
Sensors
 Transmissive gap sensor
 Black mark reflective sensor
 Head open sensor
Real Time Clock
Standard
