TSC DA210 Series User Manual

19
4.4 Loading Media in Peel-off Mode (Optional for DA220 series)
1. Please refer to section 3.2 to install the media.
Place the label leading edge onto the platen roller.
2. Close the top cover gently. Use software to make
calibration and set the post-print action to “PEEL”.
You may refer to Chapter 5 for configuring the
printer.
3. Move the media guides to fit the label width by
pushing the media guide adjustment button.
4. Close the peel-off cover and printer cover.
NOTE: Make sure the latches of peel-off cover
are correctly secured by the printer cover.

TSC DA210 Series Specifications

General

Resolution	203 dpi / 300 dpi
Print Speed	Up to 6 ips (inches per second)
Processor	32-bit RISC
Interface	USB 2.0
Scanning Technology	Thermal transfer / Direct thermal
Scanning Speed	Up to 6 ips (inches per second)
Scanning Resolution	203 dpi / 300 dpi
Scanning Distance	N/A (Not applicable for barcode printers)
Additional Interface	Bluetooth (optional)
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5 ~ 40°C (41 ~ 104°F)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Humidity	20% to 85% (non-condensing)
Supported Barcode Types	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, PDF-417, DataMatrix, QR code
