- 7 -
2.2 Printer Overview
2.2.1 Front View
For MB240 Series
1. LED indicator
2. Icons and LED indicators
3. Front panel buttons
4. Media view window
5. Paper exit chute
6. Media cover handle
1
4
5
3
2
6
