- 17 -
6. Wind the ribbon rewind spindle
counterclockwise roughly 3~5 circles
until the ribbon is smooth, properly
stretched and wrinkle-free.
7. Close the print head mechanism by
pushing down the both sides of the
print head release lever.
Note:
* Please refer to video on TSC
YouTube.
Ribbon loading path
Ink coated outside
Ink coated inside
