1. Ribbon rewind spindle
2. Print head pressure position adjustment knob
3. Print head pressure adjustment knob
4. Print head release lever
5. Ribbon supply spindle
6. TSC website QR Code
7. Label supply spindle
8. Media near end sensor
(movable, MH240T/MH240P Series only)
9. Label roll guard
10. Media guide bar & rear label guide
11. Media rewind guide
12. Media rewind spindle
13. External label entrance chute
14. Damper
15. Media lower cover
16. Print head
17. Platen roller
18. Label guide
19. Ribbon sensor
20. Black mark sensor (shown as↓)
21. Gap sensor (shown as ▽)
