TSC MH240 User Manual

2
1.1 Product Specification
1.1.1 Product standard feature
STANDARD
ADVANCED
Model
MH240
MH340
MH640
MH240T
MH340T
MH640T
MH240P
(w/ internal
full
rewinder)
MH340P
(w/ internal
full
rewinder)
MH640P
(w/ internal
full
rewinder)
Resolution
203
dots/inch (8
dots/mm)
300
dots/inch (12
dots/mm)
600
dots/inch
(24
dots/mm)
203
dots/inch (8
dots/mm)
300
dots/inch
(12
dots/mm)
600
dots/inch
(24
dots/mm)
203
dots/inch (8
dots/mm)
300
dots/inch
(12
dots/mm)
600
dots/inch
(24
dots/mm)
Printing
method
Thermal transfer & direct thermal
Mechanism
Die-cast base and frame/ Metal cover with two hinges & large clear media view window
LCD display/
Operation
buttons
 14 anguages selectable
 3.5” color TFT display, 320 x 240
pixel
 6 operation buttons (menu,
feed/pause, up, down, left, right)
 1 LED (with 2 LEDs / Green &
Red)
 14 languages selectable
 Large Backlit LCD display (16 bits Color, 4.3" 480 x 272 pixel touch LCD
display ; Resistive Touch Screen)
 6 operation buttons (menu, select, up, down, left/pause, right/feed)
 1 LED (with 2 LEDs / Green & Red)
Processor
32-bit RISC high performance processor
Memory
 512MB Flash memory
 256MB SDRAM
 USB device memory (FAT32)
 microSD card, up to 32 GB

TSC MH240 Specifications

General

Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum printing width	104 mm
Display type	LCD
Product color	Black
Built-in display	Yes
Display resolution	320 x 240 pixels
Maximum media length	25400 mm
Maximum roll diameter	203.2 mm
Supported paper width	20 - 114 mm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Serial interface type	RS-232
Connectivity technology	Wired & Wireless
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	25 - 85 %
Sustainability certificates	ENERGY STAR
Ethernet LAN data rates	10, 100 Mbit/s
Flash memory	512 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	1D, 2D, AZTECCODE, Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Code-128 Codabar Library, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, Interleaved 2/5, MaxiCode, MicroPDF417, PDF417, QR Code, UPC-A, UPC-E
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Page description languages	TSPL-EZ

Weight and Dimensions

Depth	502 mm
Width	276 mm
Height	326 mm
