TSC MH240 User Manual

67
UL 60950-1 (2nd Edition)
CSA C22.2 No. 60950-1-07 (2nd Edition)
EN 62368-1
KN 32
KN 35
이 기기는 업무용(A 급) 전자파적합기기로서 판매자 또는 사용자는 이 점을 주의하시기 바라며,
가정외의 지역에서 사용하는 것을 목적으로 합니다.
GB 4943.1
GB 9254, Class A
GB 17625.1
此为 A 级产品，在生活环境中，该产品可能会造成无线电干扰，
在这种情况下，可能需要用户对干扰采取切实可行的措施。
Energy Star for Imaging Equipment Version 2.0
IS 13252(Part 1)/
IEC 60950-1
Note: There may have certification differences in the series models, please refer to product label for accuracy.

TSC MH240 Specifications

General

Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum printing width	104 mm
Display type	LCD
Product color	Black
Built-in display	Yes
Display resolution	320 x 240 pixels
Maximum media length	25400 mm
Maximum roll diameter	203.2 mm
Supported paper width	20 - 114 mm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Serial interface type	RS-232
Connectivity technology	Wired & Wireless
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	25 - 85 %
Sustainability certificates	ENERGY STAR
Ethernet LAN data rates	10, 100 Mbit/s
Flash memory	512 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	1D, 2D, AZTECCODE, Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Code-128 Codabar Library, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, Interleaved 2/5, MaxiCode, MicroPDF417, PDF417, QR Code, UPC-A, UPC-E
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Page description languages	TSPL-EZ

Weight and Dimensions

Depth	502 mm
Width	276 mm
Height	326 mm
