2.3.1 LED Indicat
ion and Key
pads
LED indication:
Keypad
s:
Keyp
ads form
Item name
Function
Select keys
Feed, Pause, Comfirm, Cancel.
Navigational keys
Select
/
Navigate.
LED
Status
Indication
POWER
Off
Printer power off
On
Printer power on
ON
-LINE
On
Printer is ready
Blinking
Printer is paused
Printer is downloading data
ERROR
Off
Printer is ready
On
Carriage open or cutter error
Blinking
No paper, paper jam or no ribbon
14
16
