TSC MX241P Series User Manual

18
6. Adjust the front label guide (green) to fit the label
width.
7. Move the media sensor by adjusting the media sensor
position adjustment knob, make sure the gap or black
mark sensor is at the location where media gap/black
mark will pass through for sensing.
8. Close print head release lever and label guide bar
release lever.
9. Set media sensor type and make calibration.
Black mark (Blue)
Print head
GAP (White)
Print
head
