TSC MX241P Series User Manual

61
Customized
Use GPIO setting commands for customized settings. For GPIO command, please
refer to TSPL/TSPL2 programming manual.
Start Print SIG
This determines the trigger conditions for the printer to control GPI 1 and GPI4.
Level mode
Error On
Pause
When this option is enabled and the printer is paused, the error signal (GPO_2) is LOW.
Enable
Ribbon Low
Mode
When this option is enabled and the printer is Low Ribbon (GPO_1), the printer will generate a warning.
Enable
Ribbon Low
Output
When the Ribbon Low Mode feature is enabled, this parameter determines if the output signal on Pin 9
(GPO_1) is HIGH or LOW.
Active High
Backfeed
This determines the timing of pullback.
Default
Reprint Mode
When this option is disabled, the printer reprint function (GPI_4) will be invalid.
Disable
