5.1 Suggestion of Ribbon Tension Adjustment
For 4” width ribbon
If the ribbon width is 4”, adjust both ribbon tension adjustment knobs to the #1 on ribbon supply & rewind
spindles. (Factory default tension is #1)
For 3” width ribbon
If the ribbon width is 3”, adjust both ribbon tension adjustment knobs to the #2 on ribbon supply & rewind
spindles.
Ribbon Supply Spindle
Tension # 1
Ribbon Rewind Spindle
Tension # 1
Ribbon Supply Spindle
Tension # 2
Ribbon Rewind Spindle
Tension # 2
