2.2 Print Engine Orientation
The PEX-1000 series are available in a left-hand configuration and a right-hand
configuration.
PEX-1121/ PEX-1131/ PEX-1161 series
PEX-1221/ PEX-1231/ PEX-1261 series
Left-hand model
Right –hand model
Note:
This document is going to show the components inside the media compartment of a left-
hand print engine. A right-hand unit contains a mirror image of those components.
Familiarize yourself with those components before continuing with the print engine setup
procedure.
