Page #9 background image
4
Leitcode, LOGMARS
2D barcode list: CODABLOCK F mode, GS1 DataBar, GS1 DataMatrix, Maxicode, AZTEC,
PDF417, QR Code, Micro PDF417, TLC39
Font & bar code rotation
0, 90, 180, 270 degree
Printer language
TSPL-EZD (Compatible to EPL, ZPL, ZPL II, DPL)
Media type
Continuous, black mark, label with gap, notch media, punched hole media
Media width
19 mm ~ 112 mm
Media thickness
0.055mm~0.0254mm
Media ID core
1” and 1.5” paper core
Label length
3 mm ~ Max. length
Environment condition
Operation: 5 ~ 40˚C, 25~85% non-condensing
Storage: -40 ~ 60 ˚C, 10~90% non-condensing
Safety regulation
FCC Class B, CE Class B, RCM, UL, cUL, TUV/safety, CCC, BIS, EAC, BSMI, KC, Mexico CoC
Environmental concern
Comply with RoHS, WEEE, REACH
Accessories
Windows labeling software CD disk
Quick start guide
USB cable
Power cord
External universal switching power supply
1” ribbon spindle x 2 pcs
1” ribbon paper core x 1 pcs
Factory option
Internal Bluetooth 5.0 MFi
Parallel port (factory option)

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TSC PRINTRONIX TX210 Series and is the answer not in the manual?

TSC PRINTRONIX TX210 Series Specifications

General IconGeneral
Print MethodThermal Transfer / Direct Thermal
Max. Print Speed8 IPS (203 mm/s)
Max. Print Width4.09" (104 mm)
Roll Capacity5" (127 mm) OD
Ribbon Length984' (300 m)
Operating Temperature41°F to 104°F (5°C to 40°C)
Resolution203 dpi
Memory64 MB SDRAM
Media TypeContinuous, Die-Cut, Fan-Fold, Black Mark
Media Thickness0.0024" (0.06 mm) to 0.01" (0.25 mm)
Processor32-bit RISC
InterfacesUSB, Serial, Ethernet
Barcodes1D and 2D barcodes
