TSC TDP-225

6
3. Separate the media holders to the label roll width.
TDP-225 model TDP-225W model
4. Place the roll between the holders and close them onto the core.
TDP-225 model TDP-225W model
5. Place the paper, printing side face up, through the media guides, media sensor and place
the label leading edge onto the platen roller.
TDP-225 model TDP-225W model
Media guides
Platen roller
Senso
r
