 BITMAP
Description
This command draws bitmap images (as opposed to BMP graphic files).
Syntax
BITMAP X,Y,width,height,mode,bitmap data…
Parameter
Description
X
Specify the x-coordinate
Y
Specify the y-coordinate
width
Image width (in bytes)
height
Image height (in dots)
mode
Graphic modes listed below:
0: OVERWRITE
1: OR
2: XOR
bitmap data
Bitmap data
Example
 X size 2 bytes

Y size 16 dots
1-byte
2-byte
