Setup
3.1 Setting Up t
he Print
er
1. Place the printer on a flat, secure surface.
2. Make sure the power switch is off.
3.
Connect the printer to the computer with the Centronics or USB cable.
4
Plug the
DC
power cord into the power jack at th
e rear of the printer
, and then
plug the
AC power cord into a properly grounded receptacle.
Note: When plug
power code into the rear of
printer please m
ake sure the print
er power sw
itch is
off.
Power Cord
Power Switch
Power Supply
Plug
USB
RS
-232C
Centronics
Power Jack
8
10
