TSC TTP-243 Pro Series

12
* Rear view
TTP-243 Plus/ 243E Plus/ 342 Plus series
1. Power On/Off Switch
2. Power Supply Connector
3. RS-232C DB-9 Interface Connector
4. Centronics Interface Connector
5. Label Insert Opening (For use with external labels)
TTP-243 Pro/243E Pro/ 342 Pro series
1. Power On/Off Switch
2. Power Supply DC Jacket
3. RS-232C Interface Connector
4. USB Interface Connector
5. Label Insert Opening (For use with external media)
6. Centronics Interface Connector (Factory option)
Note:
The interface picture here is for reference only. Please refer to the product specification
for the interfaces availability.
1
2
3
4
5
6
